Overview
Overview

Rotary Rakes

Designed to fit both custom and commercial operations, RK Series single, dual and quad rotary rakes gently sweep your crop into even, fluffy windrows for faster drying and better baling.
Specifications
Model
MF RK Series
Year
2023
Sale Type
New
Manufacturer
Massey Ferguson
Quantity
1
Manufacturer Qty
0
Model
MF RK 842 SD-TRC PRO
Rotor Delivery
Right-Hand, Center and Right-Hand
Weight Lb. (kg)
5,390 (2,450)
Working Width Ft. (m)
25'7" (7.8) - 27'7" (8.4)
Transport Width Ft. (m)
9'7" (2.96)
Power Requirements HP (kW)
60 (44.7)
features
  Features

Innovation

RK Series Rotary Rakes

From its innovative suspension to its clean gathering action (without all that dirt and debris), the RK Series delivers a well-formed windrow that leads to higher quality hay.

Build the perfect windrow

Cam-action tine arms per rotor and a heavy-duty vinyl curtain let you easily adjust raking action and windrow width

Floating along

Our unique RotorFlex suspension lets rotors “float” from front to back & side to side to cleanly gather the crop into a more manageable windrow

Down with dirt

"Jet effect" lifting & lowering means the front lifts first and lowers last, so tines don't dive into the ground - and there's less dirt in your crop

We have lift-up

The RK series rakes are all equipped with a headland position feature meaning rotors do not need to be switched off at the end of the field.
specifications
Model Working Width: ft (m) Transport Width: ft (m) Power Requirements: hp (kW) Rotor Delivery
RK361DSR 11'6" (3.5) 5'11" (1.56) 27 (20) Right hand
RK451DN 14'7" (4.5) 6' (1.8) 41 (30) Right hand
RK451TR 14'7" (4.5) 6' (1.8) 41 (30) Right hand
RK662SD-TRC 18’10” (5.5)-21’10” (6.6) 9’9” (2.98) 26 (19) Right hand or
center and right hand
RK702TR-SDX 20’8” (6.3)-23’ (7) 7’7” (2.3) 45 (34) Right hand
RK772SD-TRC 21’8” (6.6)-25’3” (7.7) 7'10” (3) 41 (30) Right hand or
center and right hand
RK802TRC-PRO 23’7” (7.2)-26’3” (8) 9’9” (2.98) 48 (35) Center delivery
RK1254TRC-PRO 41’ (12.5) 9’10” (3) 80 (60) Center delivery



key benefits

Massey Ferguson RK Series Rotary RakesMF RK Series - Innovation

From its innovative suspension to its clean gathering action (without all that dirt and debris), the MF RK Series delivers a well-formed windrow that leads to higher quality hay.

Massey Ferguson RK Series Rotary Rakes3900 Series - INNOVATION

Imagine a rake that floats along the ground but also hugs it closely to pick up more — then leaves large, fluffy, square-shouldered windrows. That's the innovative 3900 Series.

Massey Ferguson RK Series Rotary Rakes3900 Series - CAPABILITY

Talk about productivity. All wheels of the 3900 Series are on the ground at the same time, so they pick up the hay other rakes can leave behind.
productivity


Massey Ferguson RK Series Rotary RakesBUILD THE PERFECT WINDROW

Cam-action tine arms per rotor and a heavy-duty vinyl curtain let you easily adjust raking action and windrow width.


Massey Ferguson RK Series Rotary RakesFLOATING ALONG

Our unique RotorFlex suspension lets rotors “float” from front to back and side to side to cleanly gather the crop into a more manageable windrow.


Massey Ferguson RK Series Rotary RakesDOWN WITH DIRT

"Jet effect" lifting and lowering means the front lifts first and lowers last, so tines don't dive into the ground — and there's less dirt in your crop.


Massey Ferguson RK Series Rotary RakesWE HAVE LIFT-UP

The RK Series rakes are all equipped with a headland position feature, meaning rotors do not need to be switched off at the end of the field.
comfort


Massey Ferguson RK Series Rotary RakesDURABLE FRAME

A rugged box-beam frame ensures both stability on rough terrain and a long service life.


Massey Ferguson RK Series Rotary RakesRUGGED WHEELS

Uses the same 55-inch diameter rake wheels as used on the MF 3900 Series for efficient handling of heavy crop materials and easy replacement (60-inch diameter rake wheels standard on MF 1510 S and MF 1512 S models).

Massey Ferguson RK Series Rotary RakesBETTER PICKUP

Rake wheels mounted in pairs on pivoting brackets oscillate over field contours and pick up material that others miss.

Massey Ferguson RK Series Rotary RakesADJUSTABLE WHEEL BEAMS

An adjustable drawbar clevis allows you to level the rake wheel beams to match the tractor drawbar height.

Massey Ferguson RK Series Rotary RakesCHOICE OF RAKING WIDTHS

Your choice of three raking widths on each model (10 raking widths available on MF 1510 S and MF 1512 S models), so you can fine-tune your width by simply adjusting the turnbuckle on each wing.


Massey Ferguson RK Series Rotary RakesLIFT WINGS INDIVIDUALLY

MF 1500 S Series rakes allow operators to lift either the left or right wing individually to form a single windrow from either side. This is especially useful when cleaning up a field or working around obstacles.
mf productivity


Massey Ferguson RK Series Rotary RakesGROUND HUGGER

Thanks to the MF 3900 Series' close-to-the-ground flotation design, the large diameter rake wheels sweep fields clean.


Massey Ferguson RK Series Rotary RakesSPREAD YOUR WINGS

Get exact windrow widths with hydraulic fold wings — and stay on the move with a hydraulic cylinder on each side that lifts the rake wheels.


Massey Ferguson RK Series Rotary RakesPICK-UP ARTIST

Spring-loaded wheels with an independent pivoting arm mean you pick up hay like never before.
farm management


Massey Ferguson RK Series Rotary RakesTOUGH TEETH

Forty strong teeth per wheel give you cleaner fields and a longer wheel life.


Massey Ferguson RK Series Rotary RakesRAKE IT ALL IN

The MF 3900 Series is offered in 12- or 14-wheel versions with working widths up to 28 feet for maximum raking efficiency whether you're square or round baling.


Massey Ferguson RK Series Rotary RakesPIN IT UP

One side of the rake can be pinned up for raking single windrows or windrow turning.
available models

Model

Working
Width ft. (m)

Transport
Width ft. (m)

Power
Requirements
HP (kW)

Rotor Delivery

Weight lb. (kg)
RK 361 DN 11'10" (3.6) 5'11" (1.56) 27 (20) Right-Hand 924 (420)
RK 451 TR 14'9" (4.5) 6' (1.8) 41 (30) Right-Hand 1,320 (600)
RK 662 TRC 19' (5.8) – 21'5" (6.5) 9’ (2.75) 26 (19) Center 2,976 (1350)
RK 662 SD-TRC 18’10” (5.5) - 21’10” (6.6) 9’9” (2.98) 26 (19) Right-Hand, Center and Right-Hand 3,410 (1,550)
RK 772 SD-TRC 21’8” (6.6) - 25’3” (7.7) 7'10” (3) 41 (30) Right-Hand, Center and Right-Hand 4,620 (2,100)
RK 802 TRC PRO 23’7” (7.2) - 26’3” (8) 9’9” (2.98) 48 (35) Center 4,510 (2,050)
RK 842 SD-TRC PRO 25'7" (7.8) - 27'7" (8.4) 9'7" (2.96) 60 (44.7) Right-Hand, Center and Right-Hand 5,390 (2,450)
RK 1002 TRC 28'10" (8.8) – 32'10" (10) 9'4" (2.87) 70 (25) Center 6,393 (2900)
